electra cables

Overview 4-core, 14-strand unscreened security cable on a 100m roll. 4 × 14/0.20mm tinned copper conductors, PVC-sheathed. The standard cable for alarm system wiring in residential and small commercial installations where shielding isn't required. Where it's used Used for hard-wired alarm system installation —...

Overview 4.0mm single core building wire with black PVC insulation on a 100m drum. Copper conductor, PVC-insulated, built to AS/NZS 5000.1. The black colour identifies this as active (single-phase, secondary) or neutral identification under older colour scheme. Where it's used Used for subcircuit wiring...

Overview 4.0mm single core building wire with yellow/green earth insulation on a 100m drum. PVC-insulated copper conductor, built to AS/NZS 5000.1. The yellow/green colour is the mandatory earth identification under AS/NZS 3000 wiring rules. Where it's used Used for main earth conductor runs in...

Overview 4.0mm garden light cable in figure-8 construction on a 100m roll. Heavy low-voltage cable for substantial garden lighting installations where conductor cross-section needs to handle higher continuous current or longer voltage-drop-limited runs. Where it's used Main feeders on larger commercial landscape lighting installations...

Overview 4.0mm orange circular cable with 2 cores plus earth on a 100m drum. Round PVC-sheathed construction, 0.6/1kV rated, manufactured to AS/NZS 5000.1. Where it's used 4mm 2C+E orange circular is used for medium sub-mains — feeds to granny flats, larger detached structures, and...

Overview 4.0mm orange circular cable with 4 cores plus earth on a 100m drum. Round PVC-sheathed construction, 0.6/1kV rated to AS/NZS 5000.1. Where it's used 4C+E at 4mm covers three-phase sub-mains with separate neutral — typical use is supply to a sub-board feeding three-phase...

Overview 4.0mm single core, double insulated cable on a 100m drum. Red PVC inner with a separate PVC outer sheath over a single copper conductor. Used where mechanical protection and double-insulation rating are needed without the bulk of orange circular. Manufactured to AS/NZS 5000.1....

Overview 4.0mm twin and earth flat cable on a 100m drum. PVC/PVC flat construction with insulated earth. Built to AS/NZS 5000.2 for fixed installation in Australian residential and commercial circuits. Where it's used 4.0mm² is sized for dedicated appliance circuits — oven and cooktop...

Overview A 10-metre cut of 4.0mm twin and earth flat cable. Same flat TPS spec as the 100m drum — sold as a short length for finishing larger circuit work. Who buys this 10m of 4mm covers an oven or cooktop circuit extension, a...

Overview A 20-metre cut of 4.0mm twin and earth flat cable. Same drum spec, measured to length for small dedicated appliance circuit work. Who buys this 20m suits a single dedicated appliance circuit — oven, hot water unit, or air-conditioning feed in a smaller...

Overview A 50-metre cut of 4.0mm twin and earth flat cable — half-drum length for multiple appliance circuit runs. Who buys this 50m suits a residential fit-out with two or three dedicated 4mm appliance circuits — oven plus cooktop plus a hot water feed,...

Overview 4.0mm twin active flat cable on a 100m drum. Two insulated active conductors, PVC/PVC construction, no earth conductor. Built to AS/NZS 5000.2. Where it's used 4mm twin active is used for higher-current switching and active strapping between switchboards where the application doesn't include...

Overview 6-core, 14-strand unscreened security cable on a 100m roll. 6 × 14/0.20mm tinned copper conductors, PVC-sheathed. The 6-core configuration suits sensor wiring that needs additional conductors for tamper detection or end-of-line resistor circuits. Where it's used Used for alarm system wiring where the...

Overview 6-core, 7-strand unscreened security cable on a 100m roll. 6 × 7/0.20mm tinned copper conductors, PVC-sheathed. The lighter 7-strand construction suits shorter sensor runs where the smaller conductor size meets the signalling requirement. Where it's used Common for short alarm system sensor runs...

Overview 6.0mm single core building wire with black PVC insulation on a 100m drum. Copper conductor, PVC-insulated, built to AS/NZS 5000.1. The black colour identifies this as active (single-phase, secondary) or neutral identification under older colour scheme. Where it's used Used for switchboard wiring...

Overview 6.0mm single core building wire with yellow/green earth insulation on a 100m drum. PVC-insulated copper conductor, built to AS/NZS 5000.1. The yellow/green colour is the mandatory earth identification under AS/NZS 3000 wiring rules. Where it's used Used for main earth conductor runs in...

Overview A 10-metre cut of 6.0mm single core building wire with yellow/green earth insulation. Same Electra Cables drum spec, measured short for earth conductor jobs that don't need a full 100m drum. Who buys this 10m of 6.0mm earth wire suits short earth conductor...

Overview A 20-metre cut of 6.0mm single core building wire with yellow/green earth insulation. Same Electra Cables drum spec, measured short for earth conductor jobs that don't need a full 100m drum. Who buys this 20m of 6.0mm earth wire suits short earth conductor...

Overview A 50-metre cut of 6.0mm single core building wire with yellow/green earth insulation. Same Electra Cables drum spec, measured short for earth conductor jobs that don't need a full 100m drum. Who buys this 50m of 6.0mm earth wire suits short earth conductor...

Overview 6.0mm orange circular cable with 2 cores plus earth on a 100m drum. Round PVC-sheathed construction, 0.6/1kV rated, built to AS/NZS 5000.1. The orange jacket identifies it as fixed-wiring power cable suitable for conduit and protected installation methods. Where it's used 6mm 2C+E...
