Get ActronAir Serene 2 WRE-035CS 3.5kW Inverter Wall Split System - AC035CS today!
*THIS ITEM IS PICK UP ONLY*
Shop with Confidence
3.50 kW Cooling
3.70 kW Heating
R32 | 5 Star Energy Rating
|
OUTDOOR MODEL |
WRC-035CS |
|
|
INDOOR MODEL |
WRE-035CS |
|
|
Nett (Rated) Capacity (kW) (AS/NZS3823.1.1) |
Cooling (min-max) |
3.50 (1.50 - 4.90) |
|
Heating (min-max) |
3.70 (1.80 - 5.10) |
|
|
Input Power (kW) (AS/NZS3823.1.1) |
Cooling Rated |
0.73 |
|
Heating Rated |
0.77 |
|
|
(1) EER Rated (AS/NZS3823.1.1) (2) COP Rated (AS/NZS3823.1.1) |
Cooling Rated |
4.79 |
|
Heating Rated |
4.81 |
|
|
Star Rating (AS/NZS3823.1) |
Cooling |
5.5/5/5.5 |
|
Heating |
4/3.5/2.5 |
|
|
Power Supply (V / Ph / Hz) |
Outdoor |
220-240V / 1PH+ N / 50Hz |
|
Rated Load Amps (AS/NZS3823.1.1) |
Cooling |
3.2 |
|
Heating |
3.4 |
|
|
Full Load Amps (AS/NZS3823.1.1) |
10.5 |
|
|
Circuit Breaker Amps |
16.0 |
|
|
Suggested Minimum Mains Cable Size (3) |
2.5mm2 |
|
|
Suggested Minimum Indoor to Outdoor Cable Size & Type (3) |
1.0mm2 3 Core + Earth |
|
|
IP Rating |
Outdoor |
IP24 |
|
Indoor |
IP20 |
|
|
Moisture Removal (L/hr) |
1.7 |
|
|
Compressor |
Inverter Rotary |
|
|
Refrigerant |
|
R-32 |
|
Airflow Range Indoor (L/s) |
Boost |
250 |
|
High |
180 |
|
|
Medium |
120 |
|
|
Low |
100 |
|
|
|
|
|
|
Outdoor Dimensions (mm) |
Depth |
333 |
|
Height |
554 |
|
|
Width |
805 |
|
|
Indoor Dimensions (mm) |
Depth |
225 |
|
Height |
295 |
|
|
Width |
795 |
|
|
(4) Nominal Weight (kgs) |
Outdoor |
32.1 |
|
Indoor |
10.3 |
|
|
Indoor Sound Pressure Level (dBA) |
(Quiet/low/med/high/turbo) |
25/30/32/38 |
|
(5) Outdoor Sound Pressure Level (dBA) 1m |
52 |
|
|
(6) Outdoor Sound Power Level (dBA) |
58 |
|
|
Outdoor Operating Range (°C) |
Cooling |
-15°C to 60°C |
|
Heating |
-25°C to 30°C |
|
|
MEPS Compliant |
Yes |
|
|
(7) Demand Response Capability (AS4755.3) |
Capable |
|
Important Notes:
• The Local Electricity Supply Authority may require limits on - starting current, running current
and voltage drop, please check prior to purchase.
• When the outdoor temperature exceeds the rated conditions, the cooling/heating capacities
may decrease the rated nett values.
• Specifications subject to change without notice.
Rated Conditions:
Cooling: 35°C DB Outdoor / Air Entering Indoor 27°C DB, 19°C WB
Heating: 7°C DB, 6°C WB Outdoor / Air Entering Indoor 20°C DB
